Case Study

Eckhart takes steps toward improving the life of factory-floor workers.


Eckhart takes steps toward improving the life of factory-floor workers

Eckhart utilizes Stratasys materials, Nylon 12 CF and ULTEM™ 1010 resin, to produce durable, lasting solutions.

Improving life of the line.

Eckhart, a leader in advanced industrial solutions, is committed to improving the lives of factory-floor workers through safety, reliability and efficiency in manufacturing for industries from medical device to automotive.
“Industry 4.0 is really the ecosystem that is a smart factory. It takes all of the systems in a factory, ties them together to help not only those who manage the process but also to help the employees on the factory floor become more informed on the health of the system,” said Andrew Storm, Eckhart’s CEO.

“Ninety percent of Fortune 500 manufacturing CEOs believe adopting Industry 4.0 technologies is imperative,” added Dan Burseth, vice president of Eckhart. “And we build technology implementation plans with some of the largest manufacturers in the world, designing tools, equipment and automation that truly improve the life of the people tasked with running the line.”

Industry 4.0 is really the ecosystem that is a smart factory. It takes all of the systems in a factory, ties them together to help not only those who manage the process, but also to help the employees on the factory floor become more informed on the health of the system.

Customized, proven additive solutions.

Eckhart customizes factory floor solutions to address specific needs of each client, walking the floor to see exactly where ergonomics, line of site or bill of materials can be improved using autonomous guided vehicles, collaborative robotics and additive manufacturing.

“Our customers want proven solutions, durable solutions; the assembly environment is harsh.

These tools are being used 60 times an hour for an 8-hour shift, 3 shifts a day, 6-7 days a week,” said Bob Heath, Eckhart’s Additive Manufacturing Applications Engineer. “With Stratasys engineering-grade materials, Nylon 12 with carbon fiber and ULTEM™1010 resin, we are able to produce durable, lasting solutions that can hold up and withstand the rigors of an automotive environment.”

Customized, proven additive solutions
Customized, proven additive solutions

When working to streamline production for their leading industry clients, from Ford to Mercedes to Airbus, Eckhart has shown how additive manufacturing with Stratasys materials greatly improves the way things have always been done.

“Traditionally, we had to design our parts around the way we were going to manufacture them, whether it was manually machining or CNC machine, our part design was limited to our manufacturing capabilities,” said Heath. “But with additive manufacturing, the complexities and capabilities are limitless.”

This 3D printed lug nut starter is a lightweight solution that improves ergonomics and assembly speed.

Many of Eckhart’s clients have seen great benefits from small tweaks to their processes, adopting 3D printed jigs and/or fixtures for applications such as a lug nut starter, badge alignment tools and wiper alignment set fixtures.

“Pressing on badges, emblems on vehicles – these things are repetitive tasks. When we go into plant sand we pick up a badge tool, and it’s heavy, it’s either above or right at that ergonomic limit for the operator to be able to pick up 60 times an hour. So we're alleviating the repetitive injury strain on the operator,” explained Heath.


Speed and customization
Partnering for a Streamlined Future

“We provide solutions that are not replacing operators but are making up for the operators they can't hire, or projecting the ability of one operator that one can be the same as five, and additive manufacturing is one of the tools that we have to facilitate that,” said Drew Morales, director of business development and engineering systems at Eckhart.



Partnering for a streamlined future.

Eckhart recognizes time and innovation are top priorities, and all businesses are under an extreme amount of pressure to iterate faster. Eckhart sees this across the board, from heavy truck manufacturers like Caterpillar to medical device manufacturers Medtronic and Boston Scientific, to aerospace manufacturers Boeing, Airbus and Lockheed Martin.
Partnering for a Streamlined Future
