Initial and Final Inspections
Post-build, every part is given an initial quality control (IQC) inspection. The standard six-point inspection includes measurement of the X, Y and Z dimensions, a visual inspection of the surface finish (overall aesthetics and intact features), a flatness or warp check, and a FOD (foreign objects or debris) check. This usually occurs before the part is post-processed (ex. painted or plated) and before it’s shipped.
After post-processing and before shipment, all parts are given final inspections from the Quality Control team. The six-point inspection is used again to ensure correct measurements and specifications. If the result of these inspections are aligned with the customer’s defined needs, the parts are packaged and shipped. If needed, we can include in the shipment a certificate of conformance, which certifies the parts meet customer specifications, and/or a material certificate to confirm the material type, composition and relevant manufacturing data.
Solutions for Your Custom Needs
Because so many of the parts built with our 3D printing technologies are custom designs, they often hold custom quality assurance requirements. This is where our team shines; our quality assurance expertise lends to the development of custom quality checks and inspections perfectly suited to your application and needs.
Outside of our typical offerings we can provide complete inspection to engineering drawings, 3D laser scanning, measurement via coordinate measuring machine (CMM), verification using a fit check fixture, alternate measurement verification for specific features, like diameter and hole-to-hole, and first article inspections.
3D printing has the benefit of speed – our production processes get you to market faster than other conventional methods. However, the reduction in lead times doesn’t sacrifice the quality delivered. Our certified systems ensure you receive your part within the parameters customized to your unique requirements.
