Embry-Riddle RobotX Challenge submarine rises to the challenge.
January 26, 2022
3D printing provides solution for questions about mounting geometries.
3D printed solutions.
Students at Embry-Riddle Aeronatical University
(ERAU), wanted the best of everything when
it came to the submarine they entered in the
Maritime RobotX Challenge, off Sand Island,
Hawaii. Team Minion, with members from 11th
grade students to Ph.D. candidates in software,
electrical and mechanical engineering, wanted
“more than a hull with okay shape and okay
structure,” said Chris Hockley, Ph.D. candidate.
What they wanted was a streamlined and
watertight vessel. And, of course, they wanted to
win the international competition.
Team members were charged with securing
sponsors to help fund travel and hardware for
their challenge sub and boat. The 16-foot robotic
boat or WAM-V, had to be transformed into an
autonomous seagoing robot that used cameras,
lasers and sonar. Team Minion had planned for
the robot to deploy a submarine, but instead
chose to deploy an autonomous seagoing robot
that rode on the surface of the water with a
submersible camera.
Since their 2014 vessel entry, Team Minion employed a fundamental design shift, choosing to make their vessel an autonomous, reconfigurable sensor platform. “Because we needed the vessel to have communication with the surface at all times, it wasn’t possible to deploy a true submarine,” said Hockley. Instead, these autonomous systems feed on the information delivered to them, including weather conditions and traffic, which are communicated through sensor suites of cameras, RADAR and LIDAR. These systems are encased in a hull or housing, which needs to withstand many perils during competition, including flooding or leakage and heat build-up within the closed housing. Seeking a competitive edge, the team considered many housing options. “But we weren’t willing to sacrifice function.”
Some of the mounting geometries on the submarine are very difficult. We could not have designed a solution with subtractive technologies. 3D printing was the only technology that could provide a solution.
Dr. Eric Coyle, Embry-Riddle Aeronautical University
3D printing gives team their edge.
3D printing has been used within the engineering department at the University for a number of years
and team members quickly realized the additive process was the answer to its design challenges.
“With 3D printing, we could design for function and manufacture any shape housing we wanted to,”
said Hockley. Not only was the housing watertight but it was hydrodynamic and sleek-looking. “We
had both the mostly highly-functioning deployable submarine and the best looking vessel in the
competition,” said Hockley.
Time savings were another consideration for the team who was able to produce high precision, high
quality parts in little time with a Fortus 900mc 3D printer, using FDM Nylon 12 material. The team
began working on its entry in mid- August and had the submarine in hand in early October, ready
to begin testing. “If we’d had to manufacture the parts, we couldn’t have met the timelines,” said
Hockley. Instead of the expensive and time-consuming process of getting parts machined, “we took
measurements in CAD and then printed them off to see how it all fit.”
Deployable submarine with camera, encased in 3D printed materialDeployable submarine with camera, encased in 3D printed material.
A winning combination.
ERAU placed 4th overall in the RobotX Challenge, also winning an award for ‘Most Autonomous
System.’ “Some of the mounting geometries on the submarine are very difficult. We could not have
designed a solution with subtractive technologies. 3D printing was the only technology that could
provide a solution,” said Dr. Eric Coyle, faculty advisor to the team.
Solving real world problems, such as the challenges posed by autonomous systems, has a growing
relevance as autonomous vehicles are starting to come to market.
High quality testing, like that
performed by teams in the RobotX Challenge, gives students the kind of experience that helps them
land jobs after college. The iterative capabilities of 3D printing facilitate this and “companies are looking
for graduates with additive manufacturing experience. In the R&D areas of industry, 3D printing is
helping students gain the skills needed for employment,” said Coyle.
