Industry 4.0: Is this “fourth industrial revolution” just another buzzword boardrooms use while the machine shop is knee deep in oil & swarf? Meanwhile, nobody's bothered to do a proper inventory in the stockroom, so we’ve run out of machine screws...again. Or is industry 4.0, as some sources have you believe, the dawn of a new age representing a paradigm shift in not only how things are manufactured but how they interact with the user?

Since it means a lot of things to many different people, we’d like to share our view of Industry 4.0 - and what it means for additive manufacturing (AM).

According to a definition from the Industry 4.0 working group in Germany:

“Industry 4.0 will involve the technical integration of cyber-physical systems into manufacturing and logistics and the use of Internet of Things and Services in industrial processes. This will have implications for the value creation, business models, downstream services and work organization.”

Cyber-physical…what?!? If you ask us, this bit of jargon is worse than the Industry 4.0 buzzword. But bear with us as we try to pick it apart. It basically comes down to this: as advanced as our modern manufacturing facilities might be with lean manufacturing, quality assurance, and CNC machinery - most machines still have the behavior equivalent of a very obedient, small child.

Instructions can be given to a machine and it will follow them, to the letter. Even if this means smashing a tool right into a billet. Holes will be drilled and components assembled - even if they’re the wrong ones or in the wrong place.

By inventing machines to automate processes that remove undesirable human characteristics such as fatigue, boredom, strength, accuracy, forgetfulness and sickness - we’ve lost some of a human’s ability to cope with the unexpected, catch mistakes and generally see the bigger picture. Arguably most manufacturing plants are too big for any team of humans to keep track of this big picture and control all logistics anyway.

This is where the ‘cyber’ in cyber-physical systems comes in. The falling cost and subsequent improvements in overall size and capability of sensors and programmable logic controllers have unlocked a vast amount of data. Everything from stocking/inventory levels, the temperature in the factory, or throughput per hour can be tracked and analyzed.

It is argued by Industry 4.0 proponents that we now have all of the building blocks to make ‘smart factories.’

Interestingly enough, smart factories don't necessarily mean factories with artificial intelligence that makes products before you even need them. It just means ‘not a totally dumb factory,’ as even simple decision-making and error-catching have big impacts on overall manufacturing process.

Industry 4.0 can be much more than pure manufacturing. It represents a cultural shift in the way we do business, design, manufacture, and interact with one another. Early industrial revolutions took humans and made them machines. Mass manufacturing and commerce forced us to do mindless repetitive jobs, a single assembly operation on a production line, or endless data entry.

Industry 4.0 concepts can give machines that little bit of intuition they lack, enabling them to do mindless repetitive jobs while still having the human oversight to cope with the unexpected. Humans are now beginning to have the freedom to work the way they work best - or want to live. Mass connectivity has enabled flexible working hours and home offices. Mass automation is forcing us to become more educated as machines finally take mindless jobs off our hands. However, a cultural shift will be required to encourage us to become more educated so we can handle these new occupations. Furthermore the software tools that carry out work need to become more intelligent to support the burdens of new jobs that require higher levels of thought and attention.

An important role will also be played by the paradigm shift in human-technology and human-environment interaction brought about by Industry 4.0.

The Technical Approach


Much of the early hype around Additive Manufacturing focused on the ability to create scalable factories of the future. While some of these benefits may be true today, Industry 4.0 and AM together enable creation of products that are first-to-market, fully customized, and (more importantly) are not static.

These possibilities can change manufacturing in profound ways. Our analysis of the resulting technology trends motivates a framework that captures activities for additive manufacturing’s move into mass manufacturing.

stratasys consulting


Model-Based Enterprise (MBE) Architecture


Step one on the road to advanced manufacturing is moving away from Analog 2D drawings and large quantities of disjointed metadata – and towards a standardized digital technical data package (TDP). These consist of 3D models of the proposed part and all information required to manufacture it. These models can be read and edited by any software package or piece of machinery in its product life cycle. TDPs include all of the part’s product and manufacturing information such as tolerances, toolpaths, BOMs, specifications, quality inspection procedure, packaging, and logistical information.

NIST (National Institute for Standards & Technology) has been working to standardize this for many years now, and there have been developments to the ASME Y14.41 & ISO 16792 standards - meaning Model-Based Enterprise (MBE) Architecture is becoming more widely adopted. But trying to import PMI data from your favorite CAD package to CNC machine is never as straight forward as it should be and adoption rates are still quite low. Industry 4.0 is pushing for a true digital thread, in its approach from Analog to digital conversion.

Digital Design Verification & Simulation

The design rules for additive manufacturing are far different from traditional manufacturing, and must break away from the traditional process loop of: guess, design, build, and test then redesign. Design validation and simulation for AM must be realized for industry 4.0 to reach its full potential. Digital design verification and simulation aims to test designs while you work. All of the PMI data available, coupled with expected environmental conditions the part endures in its lifetime, enables software to guide design decisions during the process.

Design verification techniques must assess a part design for functionality, manufacturability, and conformance to industry-specific quality management systems, and simulation results which allow for AM design freedom fully realized within the confines of validation strategies.

Digital Modelling & Simulation of Manufacturing Process


Similar to the principle above, digital modelling of manufacturing processes enables parts to be tested and adjusted prior to their manufacture via simulation.

Process modelling allows AM machines to reach their automation potential by storing past manufacturing data. Part files will adapt to account for inherent inaccuracies in the manufacturing process to produce higher fidelity parts. Eventually this process could be used to digitally certify designs and parts with minimal physical testing by simulating and accounting for the unquantifiable unknown, instead of enduring long and costly physical testing processes.

Couple Cyber & Physical Worlds


Today’s cyber- and physical-based systems work independently. For Industry 4.0, when one system state changes, it must cause an instantaneous change in all other connected systems. The cyber and physical states must become entangled in each other’s current and future possible states to create cyber-physical systems.

AM has the potential to be the most efficient method of converting data from the cyber to physical worlds. To complete this coupling, sensors, controls & connectivity (Internet of Things) must feed relevant information to connect both worlds. This data loop, its proper analysis, and interpretation are key principles of Industry 4.0.

Intelligent Machine Process Control


Machine Process Control has been around for a long time, but it’s relatively simplistic in its operation. A rolling mill might use a feedback loop to measure product thickness and adjust the gap between the rollers accordingly. Industry 4.0 gives the opportunity for truly intelligent machines driven by machine learning, continually improving the overall process, product, and materials used.

This is sometimes referred to as 'Deep Learning' - using a neural network to account for sources of ‘unknown’ variables, and past patterns to statistically conceive the correct value. The goal is to solve problems in a similar manner to the human brain, albeit more predictably and repeatedly. For example, a 3D printer which pre-emptively corrects mistakes based on the results of previously similar but not identical jobs.

Conclusion


Which of these 5 topics will cause the most impact for modern manufacturing or even mankind? It’s anybody’s guess. But even for those excited by Industry 4.0 there’s plenty of room for improvement. We’re surrounded by huge amounts of unutilized data, dumb machines unable to cope with the most basic form of the unexpected, and smart humans forced into doing mundane jobs. If you are curious to understand how AM will impact your Industry 4.0 strategy, feel free to reach out to the Stratasys Consulting team for a chat.
